13 - Transmission


Diagram #	Part Number		Description	Series	Find a Video
F2	134418700		Hub,drive ,agitator
F3	134736400		Transmission,service Kit
6	134197900		Screw,hex Washer Head ,1/4-20 X 0.437
F26	5303279394		Seal Assy,tub ,transmission
NI	134810400		Energy Guide
